- * Fitment: compatible for BMW 320i 01-05;323i / 323Ci 98-00;325i / 325Ci 01-05;328i / 328Ci 98-00;330i / 330Ci 01-06 (Compatible for BMW E46 3-Series Models ONLY)
- * High Tensile Strength Performance Spring: Front: 8 kg/mm (448 lbs/in), Rear: 7 kg/mm (392 lbs/in); Tested under a 600,000 time continuous compression test, the spring distortion was less than 0.04%
- * Adjustable Performance: Able to lower ride height by 1''-3''
- * Twin-Tube Shock Design: Used for low internal frictional resistance in order to increase efficiency and keep shock temps low
- * Al6061-T6 Material: Most components of the suspension parts are made from 6061-T6 aluminum to increase strength and rigidity
Combination offer
- A
- B
- C
- D
- E
- F
- G
- Description
- Reviews (15)
- Q & A()
- ESTIMATE SHIPPING
- INSTALLATION
- Product Installation
- Technique Instruction
Introduction
MXR-SNA coilovers are designed as an entry level for street use. It features with full length height adjustable and adjustable camber plates (applicable for some vehicles), which offers you a lowered stance, improved performance for your daily use vehicle.
Application
Compatible for BMW 3 (E46) 4-door sedan 318i; 330i; 325i; 328i; 318d; 320d; 320i,325i ;330d (02/1998-04/2005)
Compatible for BMW 3 2-door Convertible (E46) 318i; 330ci; 325ci;323ci; 320cd,330cd (04/2000-12/2007)
Compatible for BMW 3 2-door Coupe (E46) 318i; 320ci; 325ci; 330ci;320cd; 330cd; (02/1999-12/2006)
Compatible for BMW 3 Touring 5-door wagon/estate (E46) 316i; 318i; 325i; 328i; 330i; 323i; 325i; 318d; 320d; 330d; (10/1999-05/2005)
Note: not for Xi/xd 4 wheel drive, not for M3 model either
Specification
Top mounts: front pillow ball top mount with camber plate
rear pillow ball top mount
Damping: not available
Spring rate: front 8kg/mm
Spring rate: rear 7kg/mm
Adjustable height: Yes lowering 1'' to 3''
Shock type: Twin tube
Spring Preload: 7-10 mm
Color: gold
Package included
coilovers for 2 front and 2 rear
a pair wrench for height adjustment
Dimension
weight: 25320g
size: 63*51*21 cm
Feature
1. Lowered height adjustment from 1''-3'' which allow lower center of gravity and also add a more aggressive stance
2. Twin-Tube structure allows sufficient stroke within the shock absorber
3. Separate height adjustment does not affect damper stroke
4. High Tensile performance spring – STRESS TESTED OVER 600,000 times while the spring distortion is less than 0.04%. Plus the special surface treatment improves the durability and performance.
5. Height Adjustment tools included
6. Camber plate top mounts help to eliminate the need for a separate camber kit
7. Pillow ball top mount - It improves the steering feel and response
8. Most pieces in our Coilover systems, including mounts, collars and spring perches, are designed from 6061-T6 Billet Aluminum resulting in lightweight, durable and rust resistant components.
9. Full rebuildable
