- * H-Beam con rods compatible for Toyota Yaris Echo Vios 1NZFE 1NZ-FE 1.5L
- * Advertised Horsepower Rating: 600-800HP
- * Material: Forged 4340 aircraft chrome moly quality steel
- * Dimensions: Center to center length: 140.8mm; Big end diameter: 43mm; Small end diameter: 18mm ( tapered small end); Big end width: 17.91mm; Small end width: 17.91mm
- * Package Contents: 4 Pieces of H-Beam Connecting Rods; 8 Pieces of ARP 2000 3/8" Bolts (Note: Extra cost for upgrading to ARP L19 bolts)
- * Performance Con Rods
- * Advertised RPM Rating: 7000-9000 rpm
- * Fastener Tensile Strength (psi):200,000 - 230,000 psi
- * Balanced to within +/- 1 gram per end
- * The big end bores are honed to a +/-.01mm tolerance
- * Heat-treating & Shot-peened for remained consistent and strong
Combination offer
- A
- B
- C
- D
- E
- F
- G
![](/active/img/comb/icon_add.png)
- Description
- Reviews (2)
- Q & A()
- ESTIMATE SHIPPING
- INSTALLATION
- Product Installation
- Technique Instruction
- Official App
![CR-TOY-140.8](https://www.cqggedm.com/brand-max/description/b2c/en-gb/rod/default/d1.jpg)
![CR-TOY-140.8](https://www.cqggedm.com/brand-max/description/b2c/en-gb/rod/default/d2.jpg)
![High Quality Components](https://www.cqggedm.com/brand-max/keyfeature/en-gb/rod/forged-rods-cr-4/default/kf(1).jpg)
![Precision Machining Manufacturing](https://www.cqggedm.com/brand-max/keyfeature/en-gb/rod/forged-rods-cr-4/default/kf(2).jpg)
![Professional H-Beam Design](https://www.cqggedm.com/brand-max/keyfeature/en-gb/rod/forged-rods-cr-4/default/kf(3).jpg)
![High Performance Material](https://www.cqggedm.com/brand-max/keyfeature/en-gb/rod/forged-rods-cr-4/default/kf(4).jpg)
Application
Compatible for Toyota Yaris 1NZFE 1NZ-FE 1.5L
Compatible for Toyota Echo 1NZFE 1NZ-FE 1.5L
Compatible for Toyota Vios 1NZFE 1NZ-FE 1.5L
Compatible for Scion XB 1NZFE 1NZ-FE 1.5L
Specification
Performance Con Rods
Type: Forged 4340 aircraft chrome moly quality steel for racing
H-beam Conrods Quantity: 4 Pieces a set
Bolts:Including Genuine ARP 2000 bolts
Note: Extra cost for upgrading to ARP L19 bolts
Bolts Size: ARP 2000 3/8" bolts
Tolerance: Balanced to +/- 1 gram in set
Piston Bolt Hole: +-4/1000mm
Power: 600hp ~ 800hp per set
Strength of the fastening (PSI): 200,000/230,000 PSI Torque: 48ft ≈ 65 NM
Top acceleration: 7000-9000rpm
warranty: one year warranty for any manufacturing defect
Dimensions
Center to center length: 140.8mm
Big end diameter: 43mm
Small end diameter: 18mm
Big end width: 17.91mm
Small end width: 17.91mm
Feature
- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin
Note
- Professional installation is highly recommended (No Instruction Included)
- Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
