Compatible for Nissan Silvia CA18 S13 180SX 200SX Conrods Con Rod ARP 2000 Bolts Connecting Rods

lncl. 20% VAT
  • * H-Beam con rods compatible for Nissan S13 180SX Silvia CA18 CA18DET
  • * A2.Advertised Horsepower Rating: 600~800HP
  • * Material: Forged 4340 aircraft chrome moly quality steel
  • * Dimensions: Center to center length: 133mm; Big end diameter: 48mm; Small end diameter: 20mm ( tapered small end); Big end width: 24.2mm; Small end width: 21mm
  • * Package Contents: 4 Pieces of H-Beam Connecting Rods; 8 Pieces of ARP 2000 3/8" Bolts (Note: Extra cost for upgrading to ARP L19 bolts)
  • * Performance Con Rods
  • * Advertised RPM Rating: 7000-9000 rpm
  • * Fastener Tensile Strength (psi):200,000 - 230,000 psi
  • * Balanced to within +/- 1 gram per end
  • * The big end bores are honed to a +/-.01mm tolerance
  • * Heat-treating & Shot-peened for remained consistent and strong
Item Number 3002032246
Stock In Stock

Combination offer

  • A
  • B
  • C
  • D
  • E
  • F
  • G
CR-NIS-133A-20
CR-NIS-133A-20
High Quality Components
High Quality Components
With Standard ARP 2000 Bolts(Upgradable ARP L19)
Precision Machining Manufacturing
Precision Machining Manufacturing
Shot Peening for improved fatigue life. 100% CNC machined for superior tolerances, Precision rod cap alignment dowels
Professional H-Beam Design
Professional H-Beam Design
Improve stiffness, reduce stress risers and reduce weight
High Performance Material
High Performance Material
Forged 4340 aircraft chrome moly quality steel for racing

Application

Compatible for Nissan S13 Silvia 180SX Bluebird Sunny CA18 CA18DE CA18DET
Compatible for Nissan Sunny B12 1985 - 1990 CA18DE
Compatible for Nissan Bluebird U11 series 1983 - 1987 CA18ET/DET turbo
Compatible for Nissan Bluebird T12/T72 Turbo Violet T12 series 1986 - 1990 1.8 L CA18ET

Note

- Professional installation is highly recommended (No Instruction Included)
- Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.

Specification

- Performance Con Rods
- Type: Forged 4340 aircraft chrome moly quality steel for racing
- H-beam Conrods Quantity: 4 Pieces as showing in picture
- Bolts: Including Genuine ARP 2000 bolts
- Note: Extra cost for upgrading to ARP L19 bolts
- Bolts Size: ARP 2000 3/8" bolts
- Tolerance: Balanced to +/- 1 gram in set
- Piston Bolt Hole: +-4/1000mm
- Power: 600hp ~ 800PS per set
- Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
- Top acceleration: 7000-9000rpm
- Warranty: one year warranty for any manufacturing defect

Dimensions

Center to center length: 133mm
Big end diameter: 48mm
Small end diameter: 20mm
Big end width: 24.2mm
Small end width: 21mm

Feature

- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin
